Pipelines designed for the transport of crude oil, natural gas, refined oil derivatives as well as any fluid at temperature between -20°C and 120°C. It’s developed for the protection of pipelines designed and they can be used as primers for the 3 layer system in steel pipe protection. These FBE coatings are generally produced in grey and green colours, but they can be produced in different colours upon request.
Fusion bonded epoxy protects the steel from corrosion. If any holes are present in the coating and chloride ions are available in the concrete, then localized corrosion may occur. If all rebars are coated then there's only small cathodes present. Due to this corrosion rate will reduce. Corrosion rate is 50% less in coated rebar instead of
uncoated.
Rebar coated with Fusion bonded Epoxy to be used in any concrete. Some examples are:
1. Bridges
2. Highway
3. Buildings
4. Airport runway
Application process of Fusion Bonded epoxy on Rebar and Pipes
1. Substrate are shot blasted using abrasive Grit.
2. Substrate then preheated up to 220 deg. C EMT.
3. Heated Steel is passed through a powder spray booth where powder is applied on substrate by Spray Guns.
Fusion Bonded Epoxy has a very fast curing Characteristic. Its formulations are based on specially selected Epoxy resins and hardeners. Fusion Bonded Epoxy have a ability to an excellent barrier against water, oxygen, chloride, and many more elements:
ADVANTAGES OF FUSION BONDED EPOXY
1. High adhesion properties
2. Long term chemical resistance
3. High Mechanical Strength
4. Penetration Resistance
5. Hi Dielectric Properties
6. Resistance against Heat
7. Strong Resistance to Corrosive Environment
